K1110 - Dong ho van nang KYORITSU 1110, K1110

K1110

Đồng hồ vạn năng KYORITSU 1110, K1110

Lượt xem: 210 Xin vui lòng liên hệ để biết giá

Vui lòng liên hệ để có giá tốt nhất
Đặt mua sản phẩm Trở về
Hotline: 0909 63 73 78 - 0986 63 73 78
Hoạt động từ 08:00 - 22:00 hàng ngày kể cả Thứ 7 và Chủ Nhật

Trở về | Lên trên

  • Thông tin sản phẩm
  • Thông tin kỹ thuật
  • Hình ảnh sản phẩm
  • Ý kiến người dùng
• High sensitivity DC20kΩ/V.
• 1m drop-proof heavy duty designed taut-band movement.
• Can measure line voltage up to AC 600V.
(Voltage to ground MAX AC300V) (Protected by 600V ceramic fuse against accidental overload)
• Continuity buzzer, battery check, LED check, temperature measurement function.
• Skeleton type robust and clear case with carrying handle furnished as standard accessory.
1110
CE
DC V 0.3V (16.7kΩ/V) ±3% of FS
3/12/30/120/300/600V (20kΩ/V)
|±3% of FS
AC V 12V (9kΩ/V) ±4% of FS
30/120/300/600V (9kΩ/V)
|±3% of FS
DC A 60µA/30/300mA
|±3% of FS
Ω 3/30/300kΩ
|±3% of scale length
Continuity buzzer Buzzer sounds below 100Ω
LED 10mA approx. at 0 Ω
(at 3V of battery voltage)
Temperature -20ºC~+150ºC
|±3% of scale length (0ºC~+100ºC)
|±4% of scale length (other ranges)
(with the use of Temperature probe 7060)
Battery Test 1.5V (0.7~2V)
|±3% of FS (10Ω load)
Maximum
Circuit Voltage		 600V AC/DC (between line/neutral)
300V AC/DC (against earth)
Applicable standards
IEC 61010-1 CAT.III 300V Pollution Degree 2
    CAT.II 600V Pollution Degree 2
IEC 61010-2-031
Withstand Voltage 3700V AC for 1 minute
Power Source R6P (AA) (1.5V) × 2
Dimensions 140(L) × 94(W) × 39(D) mm
Weight 280g approx.
Accessories 7066A (Test leads)
8923 (F500mA/600V fuse) × 2
R6P (AA) × 2
9103 (Carrying case)
Instruction Manual
Optional 7060 (Temperature probe)
